Horizontal Wire Enamelling Machine
1650000.00 - 3500000.00 INR
Product Details:
- Product Type Horizontal Wire Enamelling Machine
- Wire Material Copper / Aluminium
- Inlet Diameter 0.15 mm to 4.0 mm
- Outlet Diameter 0.10 mm to 3.8 mm
- Insulation Material Polyester, Polyamide, Polyurethane, or customized
- Voltage 380 V / 415 V, 3 Phase, 50 Hz
- Power 50 kW to 150 kW (depending on model & capacity)
- Click to View more
X
Horizontal Wire Enamelling Machine Price And Quantity
- 01 Piece
- 1650000.00 - 3500000.00 INR
- Multi-stage water cooling
- Single or Multi-spool
- Emergency stop, interlocks, exhaust system
- PLC Based Automated Control with HMI
- 600 m/min to 1800 m/min
- Electric / Gas Hot Air Recirculation
- Pad, Felt or Roller Type
- Integrated Fume Extraction & Filtration
- 70 dB
- 1 to 3 (customizable)
- Up to 600C
Horizontal Wire Enamelling Machine Product Specifications
- 380 V / 415 V, 3 Phase, 50 Hz
- 0.15 mm to 4.0 mm
- Copper / Aluminium
- Wire Enamelling Process for Magnet Wire Production
- Industrial Blue / Custom
- Up to 12,000 kg (varies by configuration)
- 12000 mm x 2500 mm x 2600 mm (Approx.)
- 50 kW to 150 kW (depending on model & capacity)
- 0.10 mm to 3.8 mm
- Horizontal Wire Enamelling Machine
- Polyester, Polyamide, Polyurethane, or customized
- Multi-stage water cooling
- Single or Multi-spool
- Emergency stop, interlocks, exhaust system
- PLC Based Automated Control with HMI
- 600 m/min to 1800 m/min
- Electric / Gas Hot Air Recirculation
- Pad, Felt or Roller Type
- Integrated Fume Extraction & Filtration
- 70 dB
- 1 to 3 (customizable)
- Up to 600C
Horizontal Wire Enamelling Machine Trade Information
- Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
- All India
Product Description
Horizontal Wire Enamelling Machine features a user-friendly interface with analog meters to adjust its functioning parameters safely. Workers use this machine for copper and aluminum wires enameling because of its low power consumption and excellent environmental protection. The machine allows horizontal wire enameling at high speeds with inline drawing. The team provides this machine to you with automatic transverse boundary when winding up. Use of this machine has been increased for several appliances construction such as actuator heads, motors, speakers, transformers and so on. We provide this Horizontal Wire Enamelling Machine in standard technical specifications to allow wires or cables enameling in vibrant ranges.
Efficient and Flexible Enamelling Solutions
Our Horizontal Wire Enamelling Machine delivers unmatched flexibility in the wire enamelling process, enabling high speed production with customizable ovens, and supporting both pad, felt, or roller application. Robust safety mechanisms and environmental controls guarantee reliable, clean operation. The system is ideal for manufacturers demanding precision, adaptability, and scalability in magnet wire production.
Advanced Automation and Quality Control
The PLC-based automated control system, complemented by an intuitive HMI interface, ensures accurate process control and consistent product quality. Multiple wire diameters and insulation materials are managed easily, with a multi-stage water cooling process and controlled baking temperatures up to 600C.
FAQs of Horizontal Wire Enamelling Machine:
Q: How does the Horizontal Wire Enamelling Machine handle different wire materials and sizes?
A: This machine is engineered to process both copper and aluminium wires across a range of inlet diameters from 0.15 mm to 4.0 mm, and can produce outlet diameters as fine as 0.10 mm. Adaptable settings accommodate various insulation materials as required by the application.Q: What are the benefits of the customizable number of enamelling ovens?
A: With 1 to 3 ovens configurable, the equipment allows manufacturers to tailor the wire enamelling capacity and efficiency according to production scale, improving throughput and operational flexibility.Q: When is the integrated fume extraction and filtration system useful?
A: The integrated system is particularly valuable during the high-temperature baking phase, capturing hazardous fumes and particulates to protect operators and minimize environmental impact.Q: Where can this wire enamelling machine be installed?
A: Designed for industrial settings, this equipment is suitable for wire manufacturing facilities. Its robust build and customizable features make it versatile for various plant layouts and production requirements.Q: What processes are managed by the PLC-based automated control system?
A: Automated controls oversee key processes such as enamelling application, oven temperature, line speed, and cooling stages. The HMI interface enables real-time monitoring and parameter adjustments for optimal quality.Q: How do the safety features enhance operational security?
A: Safety is ensured through emergency stop functions, interlocks, and an exhaust system, all working together to protect users and machines during critical scenarios.Tell us about your requirement
